QC11K Series
Classification:
keyword:
Hydraulic shearing machine
WhatsApp：+86-13969473068
- Details
- Standard accessories
- Optional accessories
-
- 商品名称: QC11K Series
All steel welded structure, vibrating treatment of ageing for removal of internal stress, with good rigidity and stability. Remove rust with sand-blast and coated with anti-rust paint Frames, assembly surfaces and connection holes are machined after the welding process,up to 60' in a single pass. All pipes, flange and joint with vibrations proof and leakage proof design and setting . Overload overflow protection is outfitted to hydraulic system,which can assure no leakage,and the oil level can be read or seen directly. The hydraulic system is made in compliance with current regulations. Electrical Cabinet under the standard of IP65, Electrical under international CE Standard, safe and reliable, strong anti interference capability. Protective fence and the safety interlock to ensure the operation safety. Have a movable single-hand pedal switch,easy to operate. Front Side Covers with safety switches, Back light safety guards,Foot pedal conforming to CE regulation. Shearing angle is Variable, which can reduce the shearing deformation of sheet metal and can shear much thicker sheet metal. Function of shearing in sections, function of aligning with light. Upper blade holder has inward tiling structure to facilitate material feed in and also enhance accuracy of the work piece. Rectangular blades with four cutting edges to prolong working life, adjustable shearing angle to reduce deformation of the sheet.
QC11K Series Hydraulic Guillotine CNC Shearing Machine Model Shearing Thickness Shearing Width Throat Height Back gauge Range Shearing Angle Strokes Main Motor Power Weight (mm) (mm) (mm) (mm) (.) (mm-1) (kw) (t) 4×2000 4 2000 80 350 0.5~1 30′ 14 5.5 3.8 4×2500 4 2500 80 350 0.5~1 30′ 14 5.5 4.5 6×2500 6 2500 80 600 0.5~1 30′ 14 7.5 5.3 6×3200 6 3200 80 600 0.5~1 30′ 12 7.5 6.5 6×4000 6 4000 80 600 0.5~1 30′ 10 7.5 7.5 6×5000 6 5000 80 600 0.5~1 30′ 8 7.5 10.5 6×6000 6 6000 80 600 0.5~1 30′ 8 7.5 15.2 8×2500 8 2500 80 600 0.5~1 30′ 14 7.5 6 8×3200 8 3200 80 600 0.5~1 30′ 12 7.5 6.8 8×4000 8 4000 80 600 0.5~1 30′ 10 7.5 8.5 8×5000 8 5000 80 600 0.5~2 7 15 12.5 8×6000 8 6000 100 600 0.5~2 7 15 19.8 10×2500 10 2500 120 600 0.5~2 30′ 10 15 8.2 10×3200 10 3200 120 600 0.5~2 30′ 8 15 9.15 10×4000 10 4000 120 600 0.5~2 30′ 6 15 9.15 10×5000 10 5000 120 600 0.5~2 30′ 5 15 16 10×6000 10 6000 120 600 0.5~2 30′ 5 15 22 12×2500 12 2500 120 600 0.5~2 30′ 10 15 8.7 12×3200 12 3200 120 600 0.5~2 30′ 8 15 9.8 12×4000 12 4000 120 600 0.5~2 30′ 6 15 13.4 12×5000 12 5000 120 600 0.5~2 30′ 5 18.5 20 12×6000 12 6000 120 600 0.5~2 30′ 4 18.5 29 16×2500 16 2500 120 600 0.5~2 30′ 8 15 9 16×3200 16 3200 120 600 0.5~2 30′ 7 15 11 16×4000 16 4000 120 600 0.5~2 30′ 6 15 15 16×5000 16 5000 120 600 0.5~3 5 22 23 16×6000 16 6000 120 600 0.5~3 4 37 36 20×2500 20 2500 120 600 0.5~3 6 22 10.5 20×3200 20 3200 120 600 0.5~3 5 30 18 20×4000 20 4000 120 600 0.5~3 4 30 21 20×5000 20 5000 120 600 0.5~3 4 37 29 25×2500 25 2500 120 600 0.5~3.5 5 30 15.3 25×3200 25 3200 120 600 0.5~3.5 5 30 21 25×4000 25 4000 120 600 0.5~3.5 3 30 26 30×2500 30 2500 120 600 1~3.5 4 30 17 30×3200 30 2500 120 600 1~3.5 3 37 23 -
1. Estun E21S NC control system
2. Powered back gauge X-axis
3. American brand hydraulic system
4. Shanghai piston oil pump with low voice
5. Siemens & Schneider electric elements
6. One set of shearing blade on the machine
7. Japan NOK cylinder seals
8. Foot switch with emergency stop button
9.Hydraulic and electrical overload protection
10.Front support arms and back support
-
1. Pneumatic back support unit
2. Ball screw and Linear guide rail on back gauge
3. A lighting device on the line
4. CNC control system from ESTUN E210S, Delem DAC310 & DAC360
5. Front and side metal safe fence
