X6336WA

1. Taiwan high speed milling head
2. Automatic feeds in X, Y, Z axis
3. Hardened square guide ways
4. Manual lubricate system
5. Work table swivel 35 degree
6. Both vertical and horizontal operation are available

  • X6336WA
  • Wellon
Quantity:

Product Description

Item

X6336WA

Spindle taper

ISO40(V)  ISO50(H)

Distance from spindle to table

135-585mm

Distance from horizontal spindle to table

0-380mm

Distance from spindle to column

200-700mm

Spindle speeds

(16steps))75-4660r.p.m(V)

 (12steps))30-1800r.p.m(H)

Spindle travel

127mm

Feeding of quill

(3steps)0.04  0.08  0.15

Max drilling capacity of auto-feeding

15mm

Max rotaions angle of table

45degrees

Head movement(left/right)

45degrees

Table size

1600*360 mm

Table travel(horizontal/cross/vertical)

1000*390*450mm

Feeding range of longitudinal cross travel

(8steps)30-630mm/min

X-axis rapid feed speed

2000mm/min

Z-axis rapid feed speed

(8steps))18-300mm/min /630max

Z-axis motor power

1500W

Max weight of workpiece

450kg

T-slot number /width/distance

3/18mm/70mm

Horse power for main motor

5HP(V)4.0KW (H)

X axis driving motor

1500W

Overall dimension

2180*1950*2380

N.W./G.W.

2500/2680KG

Standard Accessories

Table swivel table

Machine Vice

Drill chuck

Reduction sleeve

Collets chuck sets

Draw bar

Mill arbors

Work lamp

Coolant system

Oil tray

CE electric

Some tools

Optional Accessories

Three Axis DRO

Spindle protection

58 pcs clamping kits

Dividing head

Rotary table

Variable spindle speed
